Description Of Rubber Spring For Dewatering Screen
Rubber spring: It is a kind of polymeric elastomer with efficient anti-vibration, small resonance region, long service life, low cost and good cold tolerance, air tightness, waterproof, electrical insulativity, and it is the best choice for reducing vibration.
Composite spring: it is a kind of cylinder elastomer compounding metal coil spring and rubber. This product is better than metal spring for its good anti-corrosive property, long lifetime and comparing with other spring, it is with efficient anti-vibration and buffering.
Advantages :
1. Excellent Anti-vibration Performance
The cylindrical structure combining springs composed of rubber with coil springs exhibits flexible performance, while allowing for larger deflection.
2. Large Load Limit
Since the combined rubber spring consists of metal spring and a unique rubber compound, a high load performance can be achieved without buckling.
3. Large Damping Effect
Use of a unique rubber compound with a high loss factor, it exhibits an excellent ability to reduce resonance amplitude.
4. Excellent sound-proof and cushioning ability
No surging which appears when metal spring is used without rubber, therefore, there is no noise caused. Due to its unique structure, it has excellent shock absorbing abilities
5. Excellent Durability and Chemical Resistance
Because this has been completed by high contour designing and compounding technologies, this rubber spring is extremely durable against mechanical aging during use and chemical aging resulting from exposure to oxygen, ozone and chemicals.
6. Easy to Mount
This can be mounted by placing a guide pin in the inner face of the rubber spring and setting a machine on it. Use a spacer if the inner diameter of the rubber spring is too large. Please contact us with any request.
|
Specification D*H*d (mm) |
Static rigidity Kg/cm |
The deformation of work (cm) |
Allowable load Pa (Kg) |
|
300*250*80 |
700 |
2.5 |
1800 |
|
250*250*50 |
600 |
2.5 |
1500 |
|
220*220*50 |
500 |
2.2 |
1100 |
|
200*200*50A |
280 |
2 |
600 |
|
200*200*50B |
420 |
2 |
850 |
|
180*180*40 |
370 |
1.8 |
700 |
|
160*160*30 |
320 |
1.6 |
520 |
|
160*130*30 |
330 |
1.3 |
450 |
|
140*160*30 |
270 |
1.6 |
430 |
|
140*140*30 |
280 |
1.4 |
400 |
|
130*130*30 |
230 |
1.3 |
300 |
|
120*120*30 |
205 |
1.2 |
250 |
|
100*130*30 |
160 |
1.3 |
210 |
|
100*100*30 |
180 |
1 |
210 |
|
80*80*20 |
150 |
1 |
150 |
|
70*70*25 |
120 |
0.8 |
120 |
|
60*80*20 |
95 |
0.8 |
95 |
|
50*45*16 |
70 |
0.5 |
60 |
Product Display Of Rubber Spring For Dewatering Screen
